Apache Cassandra Multi-Datacenter Essentials (Julien Anguenot, iLand Internet Solutions) | C* Summit 2016
Apache Cassandra multi-dc essentials
Julien Anguenot (@anguenot)
VP Software Engineering, iland cloud
1 key notions & configuration
2 bootstrapping & decommissioning new DCs / nodes
3 operations pain points
4 q&a
2
iland cloud?
• public / private cloud provider
• footprint in U.S., EU and Asia
• compliance, advanced security
• custom S...
key notions & configuration
What is Apache Cassandra?
• distributed partitioned row store
• physical multi-datacenter native support
• tailored (featu...
Why multi-dc deployments?
• multi-datacenter distributed application
• performances
read / write isolation or geographical...
Essentially…
• sequential writes in commit log (flat files)
• indexed and written in memtables (in-memory: write-back
cach...
Cassandra hierarchy of elements
8
cluster
datacenter(s)
rack(s)
server(s)
Vnode(s)
Cassandra cluster
• the sum total of all the servers in your database
throughout all datacenters
• span physical locations...
cassandra.yaml: `cluster_name`
# The name of the cluster. This is mainly used to prevent machines in
# one logical cluster...
Cassandra datacenter
• grouping of nodes
• synonymous with replication group
• a grouping of nodes configured together for...
Cassandra rack
• collection of servers
• at least one (1) rack per datacenter
• one (1) rack is the most simple and common...
Cassandra server
• Cassandra (the software) instance installed on a
machine
• AKA node
• contains virtual nodes (or Vnodes...
Virtual nodes (Vnodes)
• C* >= 1.2
• data storage layer within a server
• tokens automatically calculated and assigned ran...
cassandra.yaml: `num_tokens`
# This defines the number of tokens randomly assigned to this node on the ring
# The more tok...
Ring with Vnodes
16
Partition
• individual unit of data
• partitions are replicated across multiple Vnodes
• each copy of the partition is cal...
Vnodes and consistent hashing
• allows distribution of data across a cluster
• Cassandra assigns a hash value to each part...
Partitioner (1/2)
• partitions the data across the cluster
• function for deriving a token representing a row
from its par...
Partitioner (2/2)
• Murmur3Partitioner (default C* >= 1.2)

uniformly distributes data across the cluster based on
MurmurH...
cassandra.yaml: `partitioner`
# The partitioner is responsible for distributing groups of rows (by
# partition key) across...
Partitioner example (1/4)
22
Credits to Datastax. Extract from documentation.
Partitioner example (2/4)
23
Credits to Datastax. Extract from documentation.
Partitioner example (3/4)
24
Credits to Datastax. Extract from documentation.
Partitioner example (4/4)
25
Credits to Datastax. Extract from documentation.
Cassandra hierarchy of elements (recap)
26
cluster
datacenter(s)
rack(s)
server(s)
Vnode(s)
Cassandra Keyspace (KS)
• namespace container that defines how data is
replicated on nodes
• cluster defines KS
• contains...
Data replication
• process of storing copies (replicas) on multiple nodes
• KS has a replication factor (RF) and replica p...
Replica placement strategy
there are two (2) available replication strategies:
1. SimpleStrategy (single DC)
2. NetworkTop...
Consistency Level (CL)
• how many nodes must ACK operation at client level?
• tunable consistency at client level
• ANY
• ...
local_quorum examples
• nodes=3, RF=3 - can tolerate 1 replica being down
• nodes=5, RF=3 - can tolerate 2 replica being d...
snitch (1/3)
• determines which data centers & racks nodes belong
to
• informs Cassandra about the network topology
• effe...
snitch (2/3)
• SimpleSnitch

single DC only
• GossipingPropertySnitch

cassandra-rackdc.properties
• PropertyFileSnitch

c...
Snitch files (examples)
These properties are used with
GossipingPropertyFileSnitch and will
indicate the rack and dc for t...
snitch (3/3)
• more deployment specific snitches for EC2, Google,
Cloudstack etc.
35
cassandra.yaml: `endpoint_snitch`
# You can use a custom Snitch by setting this to the full class name
# of the snitch, wh...
seed node
• bootstrapping the gossip process for new nodes
joining the cluster
• use the same list of seed nodes for all n...
cassandra.yaml: `seed_provider`
# any class that implements the SeedProvider interface and has a
# constructor that takes ...
Gossip
• peer-to-peer communication protocol
• discover and share location and state information
about the other nodes in ...
operations pain points
operations pain points
• bootstrapping new nodes / new DCs
• repairs
• hints
• tombstones
• compactions
• indexes
• sick n...
bootstrapping new nodes / new DCs
• slow if dense nodes
• don’t expect to “just add a new node” to accommodate
load as it ...
43
# Throttles all outbound streaming file transfers on this node to the
# given total throughput in Mbps. This is necessar...
44
# Set socket timeout for streaming operation.
# The stream session is failed if no data/ack is received by any of the p...
repairs
• Anti-Entropy: QUORUM & ALL replicas compared for
CF and discrepancies fixed.
• must run before `gc_grace_period`...
repairs: what to do then?
• you must define a repair strategy from the beginning
• custom tooling
• DSE and OpsCenter
• Sp...
hints
• if node down: spool and redelivery
• slow and broken until 3.0: must truncate manually as some
are left off
• < 3....
cassandra.yaml: `hints`
max_hints_delivery_threads: 2
# Directory where Cassandra should store hints.
# If not set, the de...
compactions
• process of merging SSTables to single files
• IO heavy: GC / CPU / eat disk space
• removes tombstones
• hig...
cassandra.yaml: `concurrent_compactors`
[…]
concurrent_compactors: 2
[…]
50
tombstones
• monitor for tombstones warnings
• maintenance ops issue or application level issue?
51
cassandra.yaml: `tombstone_warn_threshold`
# When executing a scan, within or across a partition, we need to keep the
# to...
indexes
• secondary indexes? SASI?
• if looking for search:
• use DSE and its integrated search
• check https://github.com...
sick nodes
• what is the issue?
• remove “sick nodes” from the ring when it happens
54
must reads
• Datastax Apache Cassandra documentation
• http://docs.datastax.com/en//cassandra/3.0/cassandra/
cassandraAbou...
Q&A
@anguenot
http://www.slideshare.net/anguenot/
